High Impact Soffit Liner Boards

Soffit liners to reduce heat loss.

PRODUCT

AIM High Impact Soffit Liner Boards offer excellent impact resistance and are used to provide an insulated lining to semi exposed soffits. They can also be used as internal linings for walls and ceilings, especially where robustness is required.

They are available with a choice of insulation backing boards, typically Stonewool or rigid foams such as phenolic, PIR or XPS.

The fibre cement facing board can be easily decorated to match design and colour schemes.

Pre-decorated and through coloured facing boards are available.

APPLICATIONS

Suitable for use with concrete soffits where a thermal or acoustic performance is required.

FEATURES

  • Choice of insulation materials available (Stone Wool / Phenolic / PIR / XPS)
  • 6mm High impact facing boards
  • Non standard sizes also available.
  • Pre-decorated and through coloured facing boards are available.
  • Stone Wool option incorporates a Euroclass A1 insulation with a Euroclass A1 grade facing board.

BENEFITS

  • Can help achieve thermal performance of the construction.
  • Thicknesses to suit the thermal resistance (U Value) required.
  • Choice of insulation materials to suit the thermal resistance required.
  • Provides protection to the underside of soffits, especially in car parks.
  • Mineral fibre backed boards can contribute to the overall acoustic performance of the soffit / floor construction.
Download Technical Guide

Fixed direct to soffit 3D 2

Example product installation schematic using materials by others


Fixed via battens 3D 2

Soffit Liner 2 CUTOUT

PHYSICAL INFORMATION

  • Manufactured from an insulation slab bonded to fibre cement board.
  • Suitable for exposed and semi exposed applications dependant on the insulation material used.
  • High Impact rigid cement board facing:
    - 6mm thick.
    - Choice of 1200 x 600mm or 2400 x 1200mm boards.
    - Special sizes available on request.
    - Cement Board in conformance with EN 12467.
    - Euroclass A1 Non-combustible to EN 13501-1.
    - Fully external grade / frost resistant.
  • AIM High Impact Soffit Liners are supplied stretch wrapped onto pallets with a showerproof polythene pallet cover and edge protection.

Available faced with UHD decorative rock fibre board, suitable for fully exposed exterior cladding applications.

Choice of thermal and acoustic insulation:

Compression Resistant Rockfibre (CRR) - High density, high compressive strength, acoustic grade resilient rock fibre insulation slab.

Extruded Polystyrene (XPS) - Small closed cell extruded polystyrene for optimum insulation, high compressive strength and resistance to moisture.

Expanded Polystyrene (EPS) - Versatile expanded polystyrene for optimum value and light weight.

PIR - Low thermal conductivity for thinner solutions.

Phenolic (PHN) - Phenolic foam has very low thermal conductivity.

Decoration

The facing of AIM High Impact Soffit Liner Boards can be painted without any special priming using an alkali resistant paint or emulsion. Two coats of paint will usually give a satisfactory finish.

AS STANDARD

All AIM High Impact Soffit Liner Boards are made to order.

OPTIONS

AIM are able to manufacture insulation building boards with tissue or foil facings for soffit applications that do not require a high impact board finish. Please contact our sales office for further details

Soffit Liner Dimensions

The standard board configuration is either 1200 x 600mm or 1200 x 2400mm insulation faced with a 6mm fibre cement board. The thickness is determined by the thermal resistance required for the project.

TECHNICAL INFORMATION

THERMAL PERFORMANCE

AIM High Impact Soffit Liner Boards are available in a variety of insulation boards to match the thermal resistance required for the specification.

Specific thermal resistance details of the insulation materials varies according to the type and brand of insulation used. Precise details can be given on request.

U Value calculations for the project can be undertaken upon request.

ACOUSTIC PERFORMANCE

Mineral fibre backed boards can contribute to the overall acoustic performance of the soffit / floor construction.

In testing a 136mm thick, stone wool back High Impact Soffit liner board achieved a 34dB RW reduction in sound transmission. Please contact AIM for further details.

TEST REPORTS

There is no European harmonsied standard or British standard covering the manufacture, performance and specification of insulated fibre cement boards.

The base insulation used is manufactured to the relevant standard for the product.

The Fibre Cement board is manufactured to EN 12467.

Acoustic testing is covered by Z11012 – Acoustic Performance BS EN ISO 10140-2.

Please contact us for further details if required.

INSTALLATION GUIDELINES

AIM High Impact Soffit Liner Boards may be fixed directly to concrete soffit using suitable steel fasteners; the fixings supplier should be contacted for advice prior to installation, especially if a hard concrete has been specified.

Alternatively treated timber battens can be fixed to the concrete first and the AIM High Impact Soffit Liner Boards then fixed to the battens. The battens should be fixed at 300mm centres for Compression Resistant Rockfibre or 400mm centres for XPS, Phenolic and EPS, running down the length. The battens must provide at least 75mm bearing.

The Units are mechanically fixed to the battens by corrosion resistant fixings. The screws should be a pan head fixing installed with a controllable speed screw gun and not overdriven, to prevent undue compression of the insulation backing. We suggest avoiding any counter sunk fixings and hammer fixings. Please contact the sales office for more details.

Fixings are set in at least 50mm from the board edges, at the four corners of the board and at 600mm maximum centres.

Where the AIM High Impact Soffit Liner Boards are being attached to a framed backing, such as in the situation where they are being used to form a soffit under a trussed eave overhang, the framing must allow fixings at the centres specified above. Where this is not possible, or where there are problems with level alignment, a sub framing system needs to be used.

If the relative humidity of the area being lined is subject to significant variation, expansion gaps should be left between the boards to accommodate possible movement.

It may be possible to adopt a different fixing pattern dependent on the type of fixings used and the substrate in which the fixing is to be secured. Please seek advice from your nominated fixing supplier.

Where the High Impact Soffit Liner Board needs to be cut to size, a skill saw fitted with TCT blade and suitable dust extraction should be used along with the appropriate personal protective equipment.


Download Installation Guide

Fixing layout for 1200mm x 600mm high impact soffit liner boards

1200x600 boards fixed direct to soffit

Fixing direct to soffit

1200x600 boards fixed via battens

Fixing via timber battens

Fixing layout for 2400mm x 1200mm high impact soffit liner boards

2400x1200 boards fixed direct to soffit

Fixing direct to soffit

2400x1200 boards fixed via battens

Fixing direct to soffit

ITEMS REQUIRED FOR INSTALLATION

  • PPE abrasion resistant gloves
  • PPE impact resistant goggles
  • RPE dust mask - FFP3
  • PPE impact resistant goggles
  • Drill
  • Screwdriver
  • Tape measure
  • Skill Saw and TCT blade

STORAGE

Products are supplied on wooden pallets with edge protection and a shower proof hood. Products should be stored away from the elements until ready for installation.

MAINTENANCE

This product does not contain moving parts and, if undisturbed requires no routine inspections or maintenance.

DURABILITY

AIM Soffit Liner Boards are chemically inert, will not sustain vermin and do not encourage the growth of rot, fungi, moulds or bacteria. They are compatible with all normal building materials. They do not degrade under the usual conditions found in buildings and will perform effectively for the life of the building.

HEALTH & SAFETY

The Facing Board contains crystalline silica which may be released when dry working (cutting / drilling). The insulation boards used to make AIM Soffit Liner Boards are considered to be inert articles. Product Safety and Handling Information Sheets are available covering the various insulants and facing board used.

ENVIRONMENT

Global warming potential = zero

AIM High Impact Soffit Liner Boards are manufactured from a variety of insulation materials.

For product recycling of stone wool based variants, please contact: Rockwool T: 01656 868400
E: [email protected] where the insulation used is Rockwool stone wool.

ORDERING

To order this product the following information will be required:

  • Insulation board preferred.
  • Insulation thickness or thermal resistance required.
  • Board dimensions.
  • Approximate quantity.
  • Delivery location.

All AIM products are made to order. Products are typically supplied in seven to ten working days but lead times may vary depending on existing factory commitments.

There is no minimum order quantity or value although small orders may attract transport surcharges.

TECHNICAL SUPPORT

Technical Support is available from our experienced
sales team on 01293 582 400 or
[email protected]
